Project | Parameter |
Maximum Load | 100N, 200N, 500N, 1KN, 2KN, 5KN, 10KN, 20KN, (optional within one) |
Accuracy Class | Better than 0.5 level |
Effective Force Measurement Range | 0.2%~100% (level 1)/0.4%~100% (level 0.5) |
Force Measurement Accuracy | Within ±1% of the indicated value/Within ±0.5% of the indicated value |
Test Machine Resolution | The maximum load is 1/200000, the inside and outside are not divided into files, and the resolution is unchanged throughout the process |
Effective Test Width | 40, 50mm (can be widened according to customer requirements) |
Effective Stretching Space | 400, 500, 600mm (can be increased according to customer requirements) |
Test Speed Range | 1~500mm/min |
Displacement Measurement Accuracy | Within ±0.5% of the indicated value/Within ±0.2% of the indicated value |
Deformation Measurement Accuracy | Within ±0.5% of the indicated value |
Test Bench Safety Device | Electronic limit protection |
Test Bench Return Function | Manual or automatic two options, automatic or manual return to the initial position of the test at the highest speed after the test is over |
Overload Protection | More than 10% of the maximum load, the machine automatically protects |
Fixture Configuration | A set of stretching fixture |
Host Size | 700*530*1900 mm |
Power System | Taiwan AC servo motor + drive + high precision ball screw |
Power Supply | 220V, 50HZ |
Power | 0.75KW (standard with different power motors according to different power requirements) |
Host Weight | (Approximately) 500 Kg |
